TES200 IC Tester LED Digital Meter 74 40 45 Series lC Logic Gate Tester DC7-12 V

TES200 IC Tester LED Digital Meter 74 40 45 Series lC Logic Gate Tester DC7-12 V

Regular price $74.50 AUD
Regular price Sale price $74.50 AUD
Sale Sold out
Shipping calculated at checkout.

Brand: Unbranded

EAN: Does not apply

Model: IC Tester

UPC: Does not apply

MPN: Does Not Apply

Country/Region of Manufacture: China

1. Wide application of the product is mainly to test the 74 series and 40 series of digital integration, can test more than 200 kinds of integrated circuits.

2. Simple to use, through the key operation to select the test integration

3. Rapid response, the fastest 3 seconds out of the results

4.DC wide voltage power supply, suitable for most power supplies.

5. Compact and exquisite appearance

Function:

TES200 is a digital integration tester, mainly testing 74 series and 40 series digital integration, can test more than 200 kinds of integration. Simple to use, test logic integration can also determine which logic gate is bad. Test integration is selected by key operation.

Product application: digital integration test

Technical Parameters:

Operating voltage 7 ~ 12 VDC

Operating current <30 mA

Operating temperature -40°C~65°C

Storage temperature -40°C~65°C


Interface description and related operations:

JK1 power supply interface (DC header D13): is internal positive and external negative. Supply voltage (7 to 12V) DC regulated power supply

SW1 Power switch

ON: Power on state.

OFF: Power off state.

Key Description

MODE:Select the integration type. (74 series or 40 series)

UP:Select the previous integrated type.

DOWN:Selects the next integration type.

TEST:Test the selected integration type.

Caution:

The installation test integration is aligned downwards.

74 Series

7400, 7401, 7402, 7403, 7404, 7405, 7406, 7407, 7408, 7407, 7410, 7411, 7412, 7413, 7414, 7415, 7416, 7417, 7418, 7419, 7420, 7421, 7422, 7424, 7425, 7426, 7427, 7428, 7430, 7432

7433, 7434, 7435, 7436, 7437, 7438, 7439, 7440, 7442, 7443, 7444, 7445, 7446, 7447, 7448, 7454, 7464, 7470, 7472, 7473, 7474, 7475, 7476, 7477, 7478, 7480, 7482, 7483, 7485, 7486

7487, 7489, 7494, 7495, 7496, 74101, 74102, 74103, 74107, 74108, 74109, 74112,7 4113, 74125, 74126, 74128, 74130, 74132, 74133, 74134

74135, 74136, 74137, 74138, 74139, 74140, 74145, 74147, 74148, 74151, 74152, 74153, 74155, 74156, 74157, 74158, 74160, 74161, 74163, 74164, 74165, 74166, 74171, 74173, 74174, 74175, 74176, 74177, 74180, 74182, 74190, 74191, 74192, 74193, 74194, 74195, 74197, 74242, 74243, 74244, 74245, 74246, 74247, 74248, 74249, 74251, 74253, 74256, 74257, 74258, 74259, 74260, 74266


40,45 Series

cd4000, cd4001, cd4002, cd4006, cd4007, cd4008, cd4009, cd4010, cd4011, cd4012.

cd4013, cd4014, cd4015, cd4016, cd4017, cd4018, cd4019, cd4020, cd4021, cd4022.

cd4023, cd4024, cd4025, cd4026, cd4027, cd4028, cd4029, cd4030, cd4033, cd4035.

cd4040, cd4042, cd4043, cd4044, cd4048, cd4049, cd4050, cd4051, cd4052, cd4053.

cd4060, cd4066, cd4068, cd4069, cd4070, cd 4071, cd4072, cd4073, cd 4075, cd4076.

cd4077, cd4078, cd4081, cd4082, cd4085, cd4093, cd4094, cd4099, cd4502, cd4503.

cd4504, cd 4510, cd4511, cd4512, cd 4516, cd4518, cd4520, cd4522, cd 4526, cd4529.

cd4532, cd4539, cd4543, cd4555, cd4556, cd4584, cd40106, cd40110, cd 40161, cd 40162,cd40174, cd40175, cd40192, cd40193


Including led test function.
