Multicore Lead Free 96SC Tin/Silver/Copper Solder Crystal 3C 511C 0.7mm 0.5kg

Brand: Multicore

Container Size: 500gms

Solder Type: Lead Free Tin/Silver/Copper

Solder Form: Wire

MPN: Does Not Apply

Wire Diameter: 0.7mm (0.0276”)

Multicore Lead Free 96SC Tin/Silver/Copper Solder Crystal C511 3C Flux 0.7mm 0.5kg

Manufacturer Part No 309 96SC 3C 0.7MM HA 500G

Manufacturer:

MULTICORE / LOCTITE

Flux Type: Rosin

Solder Alloy: 96.5, 3, 0.5 Sn, Ag, Cu

External Diameter - Metric: 0.7MM

External Diameter - Imperial: 0.0276”

Melting Temperature: 217°C

Weight - Metric: 500g

Weight - Imperial: 1.102lb

Product Range: 309 97SC 3C 0.7MM HA 500G

Listed item is a 0.7mm 96.5/3/0.5 grade Lead-free Cored Solder Wire, made of Sn/Ag/Cu alloy. This cored wire is manufactured with a range of flux contents and although users will normally be using products with a nominal flux content of 3%.

Rosin based

Fast soldering

Pale residues

Solders difficult surfaces

Heat stable, low fuming

Mild odour
