BK8000L Bluetooth-Compatible Stereo Music Player Module DIY Amplifier Inc PCB

Brand: BEKEN IC

Type: See description

Model: BK8000L

Connectivity: Bluetooth

MPN: Does Not Apply

Bluetooth Standard: Bluetooth v2.1

Country/Region of Manufacture: China

Colour: Blue Module Green Breakout PCB

UPC: Does not apply

BK8000L Bluetooth-compatible Stereo Music Player Module DIY Amplifier Including Through Hole Breakout PCB.

Sent with Australia Post regular Letter no tracking number included.

Bluetooth specification Bluetooth V2.1

Supply voltage DC2.8-4.2V, ≤2.9V automatic shutdown, ≤3.1V alarm

Bluetooth protocol HFPV1.5, A2DPV1.2, AVRCPV1.4, HSP1.2, GAVDP1.2, IOP

Working current ≤60mA

Standby current <500uA

Temperature range -40oC ~ + 85oC

Wireless transmission range ≤10 meters

Transmission power Class2 4dbm

Sensitivity -80dBm <0.1% BER

Frequency Range 2.4GHz ~ 2.480GHz

External Interface Serial (TTL), connected to the PC need MAX232

SBC decoding audio performance

Module size 25x13.5x1.8mm

Adapter plate size 31x25mm
